CineSound Display

This unique audio display provides an intuitive view of 5.1, 6.1, and 7.1 channels of
surround sound audio. The default meter movement is from the center outward, but it
can be reversed by a selection in the AUDIO SETUP menu. Two additional channels
of audio can be viewed next to the CineSound
a total of eight channels on the screen. When the CineSound
audio inputs and meter labels follow a SMPTE 320M-B mapping scheme as listed in
Table 3-44.
®
Table 3-44. CineSound
Analog AES/EBU
Input Input
1 1
2 1
3 2
4 2
5 3
6 3
7 4
8 4
The 5.1 CineSound Audio display diagram is illustrated in Figure 3-54 and described
in Table 3-45. Figure 3-55 displays CineSound with 6.1 Channels. Figure 3-56
displays CineSound with 7.1 Channels.
General Operation
Audio Input Mapping
CineSound Display Assignment
Left
Right
Center
Low Frequency Effects (LFE)
Left Surround (LS)
Right Surround (RS)
Left Aux
Right Aux
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
®
display, if required, thereby providing
®
display is selected, the
8-Bar Display Assignment
1 Left (L1)
1 Right (R1)
2 Left (L2)
2 Right (R2)
3 Left (L3)
3 Right (R3)
4 Left (L4)
4 Right (R4)
97
