General Operation

Freeze and Freeze + Live Mode (SD-SDI and HD-SDI only)

Freeze mode contains two selections: Freeze and Freeze + Live. Selecting Freeze mode
will separate the frozen display from the live display. When SDI is high tally, data that
was captured in the cache is displayed. When the SDI button is low tally, the Live data
is displayed.
Freeze + Live is selected to show live display overlaying the captured display.
TVM Series Installation and Operation Handbook 133
