Table 3-59. Data Analyzer Setup Menu
Selection

PIXEL GROUP DISPLAY

NAVIGATION MODE

DATA SEARCH
CUSTOM DATA SEARCH
* SD-SDI and HD-SDI only

Trigger on Alarm

NOTE: Only if the alarms are enabled via the Alarms menu will an alarm occur and activate the
Trigger on Alarm feature.
Trigger on Alarm is used to freeze the waveform and vector, show where an alarm
occurred, and highlight the information for the pixel that is creating the alarm. The
highlighted pixel data is shown in the Data display. The waveform and vector then
changes color, and the pixel cursor is placed over the first pixel creating the alarm.
The pixel data that created the alarm is highlighted in red in the Data Display. For
multiple alarms, press the NAVIGATION ▲ (UP) and NAVIGATION ▼ (DOWN)
buttons to move between the pixel information of each alarm.
Press the EXIT button to clear the capture and the highlighted pixel information. The
highlighted information will reappear if the alarm is still active.

Data Display Format

The Data Display Format is used to determine the numeric base for the pixel
information that is displayed: Decimal, Hex, or Binary.
Pixel Group Display
Pixel Group Display is used to determine the cursor size and the samples displayed.
The Pixel Group Display selections are:
• 2H: 2 pixel on the same line
• 8H: 8 pixel samples from the same line*
• 2H×4V: 2 horizontal pixels and 4 vertical pixels*
* SD-SDI and HD-SDI only
Navigation Mode
Navigation mode is used to choose between three search selections. The Navigation
mode selections are NORMAL, DATA SEARCH, and ALARM SEARCH.
122
General Operation
Selection Option
2H*
8H (Default)
2H x 4V*
NORMAL
DATA SEARCH*
ALARM SEARCH*
(See Data Search on page 123 for complete List)
000 TO FFF (Hexadecimal values)
