Eye Pattern and Jitter Pane Menu Selections

Pressing and holding the EYE function button or the DISPLAY PANE button in the
active Eye Pattern pane or Jitter Waveform pane selects the pane menu. Use the
SETUP POSITION knobs or the NAVIGATION buttons to navigate the Pane menu.
The Eye Pattern Pane menu is described in Table 3-20 for SD-SDI monitoring, and
Table 3-21 for HD-SDI monitoring. The Jitter Waveform pane menu is described in
Table 3-22. The difference between the two eye menus is the Trigger Mode selections
of 10 EYE and 20 EYE.

Table 3-20. Eye SD-SDI Pane Menu Structure

Selection
JITTER HPF
TRIGGER MODE
EYE PATTERN SETUP

Table 3-21. Eye HD-SDI Pane Menu Structure

Selection
JITTER HPF
TRIGGER MODE
EYE PATTERN SETUP

Table 3-22. Jitter Waveform Pane Menu Structure

Selection
JITTER HPF
JITTER WAVEFORM
MODE
EYE PATTERN SETUP
General Operation
Selection Option
10 Hz
100 Hz
1000 Hz
OVERLAY
10 EYE
Press ENT
Selection Option
10 Hz
100 Hz
1000 Hz
OVERLAY
20 EYE
Press ENT
Selection Option
10 Hz
100 Hz
1000 Hz
10 kHz
100 kHz
Waveform Sweep
Frequency Sweep
Press ENT
