Magnification
Item
Waveform gain
Vector gain
Ethernet
Item
Standard
Connector
Performance metric
Number of simultaneous
connections
External Routing Control
Item
Switcher protocol
Number of RS-XX
Physical interconnection
standard

Power Requirements

Item
AC power source
Power consumption
Mechanical
Item
Dimensions
Weight
Environmental
Item
Operating temperature
Storage temperature
Humidity
Transportation
222
Specifications
Specification
Variable from x0.50 to x15.00
Variable: x0.50 to x10.00 in .01 steps
Specification
10/100 Base-T conforms to IEEE802.3
RJ-45
Transfer a captured frame to a PC in ≤ 30 seconds, dedicated LAN
6
Specification
RS-12X
One
RS-485
Specification
90 – 264 VAC, 50 - 60 Hz, nominal
150 VA maximum
Specification
• Height: 5.25 in. (13.34 cm)
•
Width: 8.2 in. (21.6 cm)
• Depth: 16.6 in. (42.24 cm)
9.0 lb (4.07 kg)
Specification
0° to +50°C (0° to +45°C option JEM and 3GB)
-40° to +65°C
0 to 90% (non-condensing)
24 in. (9.5 cm) impact-drop survivable in original factory packaging
