The display, shown in Figure 3-59, shows a chart that is split into three columns,
which shows the information to be identified.
• The DATA COLUMN lists the Video metadata parameter.
• The PRESENT column has two states: No data detected (blank box) and Data
Detected (indicated as present).
• The LOCATION/INFO column displays the location information from the
appropriate specification when it is detected.
Table 3-51. Sample Video Metadata Pane List
Data
10/8 BIT VIDEO
CC-1 (608)
CC-2 (608)
CC-3 (608)
CC-4 (608)
T-1 (608)
T-2 (608)
T-3 (608)
T-4 (608)
XDS (608)
DTVCC (708)
DVB TELETEXT
DVB SUBTITLES
WSS
V CHIP
VITC
AUDIO PRESENCE EMBEDDED
The second page consists of Video Indexing information for Class 1 (title only), as
shown in Table 3-52.
Table 3-52. Sample Video Index Pane (TVM-VTM-3GB only)
Data
VIDEO INDEX CLASS 1
STANDARD/ASPECT RATIO
GAMUT
SAMPLING
PAN
TILT
ZOOM
General Operation
Present
Present
Present
Present
Present
Location/info
625/50 4×3
RGB
4:0:0
PIXELS: -305.0000
LINES: -281.75
LINES: +563.5
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Location/Info
10—bit
LINE 21
LINE 21
LINE 23
1, 2, 3, 4
107
