Global Setup Menu Functions
copy the file to the USB drive. Press CANCEL to not copy the file. Pressing the EXIT
button also will not transfer the file to the USB drive.
The right column shows what is stored in the USB memory device. The stored Presets
and XGA captures on the USB drive are shown in this column.
* A file extension of ."xml" will automatically be added to the preset file name prior to
being written to the USB drive. In order for a valid preset to be loaded from a USB
drive, it must have the ."xml" extension.

Flash Update from USB

NOTE 1: Presets are lost when performing a flash update. Ensure that the presets are saved
on a USB before flashing.
NOTE 2: The menu item will not appear if a USB memory device is not installed. Disregard the
FAULT indication on the front panel during the flash update.
The FLASH FROM USB menu is used in coordination with a USB memory stick to
update the unit. Attach the USB stick into the back of the unit. Access the SYSTEM >
FLASH UPDATE FROM USB > PRESENT. The unit then proceeds into flash mode.
Flash update status is shown with the line-by-line programming and sector results.
When complete, Flash Update Complete appears on the screen. Cycle the power to
continue normal operation.
Feature Upgrade from USB
NOTE: The serial number on the device must match the serial number on the feature file.
INSERT USB DEVICE WITH FEATURE UPGRADE appears when the serial number of the
device does not match the serial number on the feature file.
The FEATURE UPGRADE FROM USB menu is used in coordination with a USB
memory stick containing the feature file for the device to update the unit. Attach the
USB stick into the front or back of the unit. Access the SYSTEM > FEATURE
UPGRADE UPDATE FROM USB menu. Press the ENT button to proceed into feature
upgrade mode. When complete, UPGRADE SUCCESSFUL appears on the screen.
Cycle the power to continue normal operation.
About
The About Screen, shown in Figure 4-9, contains the Firmware Version, VPR ID, Slot
1 ID, Slot 2 ID, Audio ID, Display firmware version, Panel version, RCU version, and
serial number information. Press the EXIT, SETUP, ENT, LEFT NAVIGATION
BUTTON, or press the LEFT/RIGHT CONTROL Knob to exit from the screen.
186 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
