Table 3-58. Description of Data Mode Display (SD-SDI and HD SDI Only)
Key Indicator
4 ELEMENTS
5 DATA
6 CURSOR
7 PICTURE ZOOM

Pixel Cursor

When selecting Data Analyzer, the pixel cursor appears on the picture display. The
Pixel cursor in the picture display shows the general location of the data displayed in
the Data Zoom pane. Look at the Picture Zoom display for the precise location of the
Data display cursor. Rotate the HORIZONTAL LEFT/RIGHT knob to move the pixel
cursor horizontally (left and right). Also, when the when the LINE button is enabled
(the LINE button is high tally), turn the CURVED ARROW knob to move the pixel
cursor vertically (up and down), and to change the line. As the cursor is adjusted, the
data in the data display changes.
The target area within the Pixel Cursor reflects the Pixel Group Display menu selection
2H, 8H, or 2H×4V.
Pressing the ENT button will access the next event determined by the DATA SEARCH
or ALARM SEARCH criteria in the data Analyzer Setup menu. Every press of the
ENT button will move the cursor to the next Data Search or Alarm Search result.
NOTE: When scrolling the data pixel cursor, the cursor will stop or disappear when it reaches
the limits of the active video. The picture zoom will continue to move within the vertical or
horizontal blanking regions. The data area, located in the lower left of the display, will continue
to scroll, and show all of the data on the line. The data will not agree with the cursor in the
Picture Zoom Area when the picture zoom stops scrolling. When the extreme horizontal or
vertical limits are reached, the pixel cursor will jump to the other side of the picture and
continue to scroll into the active video region. The picture zoom cursor and the data display will
show the same pixel information when the picture cursor is within the active video region.

Data Display Pop-Up Menu

The DATA DISPLAY menu selections are used to set Data Analyzer functions. Press
and hold the ENT button when the Data Display is shown and selected to access the
Data menu. The Data Display submenu items are described in Table 3-59.
Table 3-59. Data Analyzer Setup Menu
Selection
TRIGGER ON ALARM
DATA DISPLAY FORMAT
General Operation
Description
Elements that show the component samples for each pixel; There are
two elements per pixel sample grouping: C
Value of C , Y, C , and Y
B R
Cursor for the Data Zoom Display; Represents the exact location of the
cursor in the Picture Display (The cursor area indicates the pixels that
are represented in the Pixel, Element, and Data columns)
Zoomed portion of picture display to show precise pixel locations
Selection Option
OFF*
ON
HEX (Default)
DECIMAL
BINARY
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
, Y and C
B
l
in Decimal, Hex, or Binary form
l
, Y
R
