Filter Selection

The filters available are dependent upon the input format. The filters available are:
• Flat: No filtering.
• Low Pass: Selects the Low Pass filter.
• Chroma: Selects the Chroma filter.
• F/LP: Selects Flat and Low Pass filtering
• R-Y: Selects the R-Y filter (selection available with TVM-VTM-ACV-2 option
only)
• Bowtie: The bowtie filter is used to check the timing relationships between the
digital components. A bowtie test signal is required.

Parade and Overlay Selections

Multiple inputs can be displayed in a single pane.
• When PARADE is selected, the components of the same input are shown next to
one another (i.e. Inputs Y, then C
• When OVERLAY is selected for a single input, the components of the input signal
are displayed over each other (i.e. R over G over B in an RGB signal). When
OVERLAY is selected for A & B, like components of each input are over each
other (i.e. R over R, G over G, and B over B). A & B cannot be displayed in parade
mode.

HD or SD Format

When in the Format menu, select one of the display formats: (Y)RGB, YC
CMPST (Composite). The selected (Y) RGB, YC
a check mark. Table 3-10 lists the relationships between the input and display formats.

Table 3-10. Input and Display Format Relationship

Input Format
3 Gb/s
HD
SD
Analog Composite
(Option)

Blanking (SDI Signals only)

The blanking selections are Blank All, EAV/SAV, and Show All.
• "Blank All" displays only the active video of the input signal.
• "Show EAV/SAV" displays the active video and the EAV/SAV headers of the
input signal.
• "Show All" displays the ancillary data, EAV/SAV, and active video.
42
General Operation
, then C
B
RGB YC C YRGB
B R
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
No No No
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
in a YC C signal).
R B R
C , or CMPST text is indicated with
B R
YC C +
B R
COMP
Alpha
(10 bit only)
Yes Yes
Yes Yes
Yes No
Yes No
C , or
B R
RGB + Alpha
(TVM-VTM DLK)
(TVM-VTM-3GB
10 bit only)
Yes
Yes
No
No
