Xds - Videotek TVM9100PKG Installation And Operation Handbook

Table 3-52. Sample Video Index Pane (TVM-VTM-3GB only)
Data
WSS
PAL PLUS
ACTIVE FORMAT DESCRIPTION
Table 3-53. Video Payload Identifier and Active Format Descriptor
(TVM-VTM-3Gb Only)
Data
VIDEO PAYLOAD IDENTIFIER
LINK STATUS/BIT DEPTH
SAMPLING STRUCTURE
FRAME RATE
DIGITAL INTERFACE STD
ACTIVE FORMAT DESCRIPTION
AFD CODE
BAR DATA FLAG
BAR DATA1
BAR DATA2
PAN AND SCAN DATA

XDS

Extended Data Services (XDS) is a data service that provides current and future
program information (such as the program name, type, and content advisory
information). It also provides other related information (such as a national weather
service message and time zone information).
Press the NAVIGATION buttons to scroll through the available pages. Only the
information that is available in the video stream will appear next to the XDS field. If
the information is not available in the data stream, the displayed information following
the title is blank.
Deactivate the XDS pane by making another selection using the OPTION pop-up
menu, or pressing a different function button in the selected pane. A sample XDS pane
is shown in Figure 3-60.
108
General Operation
Location/info
Location/info
0X89c9001
100% 10 bit
4:2:2 YCbCr
TS=Prog PS= Prog 50 Hz
2.97Gb/s 1080i/p
0X50
16:9 L
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
