Table 4-9. Video Alarms, Analog Menu
Selection Selection Option
LUM LOWER
CAPTIONING CC NOT DETECTED
– ANL
CC NOT UPDATING
– ANL
TT NOT DETECTED
– ANL
TT NOT UPDATING
– ANL
Global Setup Menu Functions
Selection Option
THRESHOLD NTSC
THRESHOLD PAL
SENSITIVITY
DURATION
ENABLE
THRESHOLD NTSC
THRESHOLD PAL
SENSITIVITY
DURATION
ENABLE
DURATION
ENABLE
DURATION
ENABLE
DURATION
ENABLE
DURATION
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Selection Option
NTSC IRE:
50 TO 140 IRE
(105 is Default)
•
PAL UNITS:
51 TO 143 UNITS
(107 UNITS is
Default)
•
PAL mV:
357 TO 1000 mV
(748 mV is Default)
1 TO 20 CES (18 CES is
Default)
0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default)
ON
NTSC IRE:
-5.0 TO 10 IRE
(-2.5 is Default)
•
PAL UNITS:
-10 TO 0 UNITS
(-5 UNITS is Default)
•
PAL mV:
-70 TO 0 mV
(-35 mV is Default)
1 TO 20 CES (18 CES is
Default)
0 TO 60 SECONDS (2
Seconds is Default)
OFF (Default)
ON
0 TO 600 SECONDS (240
Seconds is Default)
OFF (Default)
ON
0 TO 600 SECONDS (240
Seconds is Default)
OFF (Default)
ON
0 TO 600 SECONDS (240
Seconds is Default)
OFF (Default)
ON
0 TO 600 SECONDS (240
Seconds is Default)
