Table 4-16. Communications Setup Menu
Selection
RCU PORT
IP CONFIGURATION
GPI INPUT
FUNCTION
162
Global Setup Menu Functions
Selection Option Selection Option
TERMINATION OFF (Default)
ON
BAUD RATE 19200 Baud
38400 Baud (Default)
57600 Baud
115200 Baud
ETHERNET CONFIG -
SCREEN
INPUT 1 SELECT A
ON AIR A
SELECT/ON AIR A
USER GPI ALARM 1
INPUT 2 SELECT INPUT B
ON AIR B
SELECT/ON AIR B
USER GPI ALARM 2
INPUT 3 SELECT C
ON AIR C
SELECT/ON AIR C
USER GPI ALARM 3
INPUT 4 SELECT INPUT D
ON AIR D
SELECT/ON AIR D
USER GPI ALARM 4
INPUT 5 RECALL PRESET 1
USER GPI ALARM 5
INPUT 6 RECALL PRESET 2
USER GPI ALARM 6
INPUT 7 RECALL PRESET 3
USER GPI ALARM 7
INPUT 8 RECALL PRESET 4
USER GPI ALARM 8
INPUT 9 RECALL PRESET 5
USER GPI ALARM 9
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Selection Option
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
