Gamut Pane Menu Selections

Pressing and holding the GAMUT function button or the selected DISPLAY PANE
button in the active gamut pane selects the pane menu. The Gamut Pane menu is
described in Table 3-30.
Table 3-30. Gamut Menu Structure
Selection

COLOR SPACE

GAMUT SETUP

Color Space
Color Space is used to determine the type of gamut graticule that appears in the pane.
Selecting RGB displays the RGB gamut graticule. Selecting CMPST displays the
Composite gamut graticule.
Gamut Setup
Press the ENT button to access the global Gamut setup menu. For more information on
the global Gamut Setup menu see Section 4.

Picture Display

The picture display pane is used to show the picture of the selected input. Press the
PICT button to display the picture in the selected pane. A Picture display diagram is
shown in Figure 3-44 and described in Table 3-31. Only one picture can be displayed.
NOTE: (Pictures can be used as thumbnails. Refer to Section 4, ""Picture Setup Menu.")
General Operation
Selection Option
RGB
CMPST
Press ENT
