Table 4-4. Eye Pattern Setup Menu
Selection

PERSISTENCE

ATTACK

Table 4-5. Vector Setup Menu
Selection
PAL OVERLAY

SDI I/Q LINES

VECTOR INTENSITY
VECTOR CONTRAST
PERSISTENCE
ATTACK
Table 4-6. Gamut Setup Menu
Selection
GAMUT INTENSITY

GAMUT CONTRAST

PERSISTENCE

COLOR PLOT

DATA ERROR PERSISTENCE

Table 4-7. Picture Setup Menu
Selection

THUMBNAIL

142
Global Setup Menu Functions
Selection Option
NORMAL, 1 to 6, & INFINITE
(NORMAL is Default)
LOW (1), 2 to 15 (NORMAL is 9), and
MAX (16) (LOW is Default)
Selection Option
NORMAL (Default)
OVERLAY
OFF (Default)
ON
25% TO 200% (100% is NORMAL)
25% TO 200% (100% is NORMAL)
NORMAL, 1 TO 6, & INFINITE
(NORMAL is Default)
LOW (1), 2 to 15 (NORMAL is 9), and
MAX (16) (LOW is Default)
Selection Option
25% TO 200% (100% is NORMAL)
25% TO 200% (100% is NORMAL)
NORMAL, 1 TO 6, & INFINITE
(NORMAL is Default)
SINGLE COLOR
RGB (Default)
NORMAL, 1 TO 6, & INFINITE
(NORMAL is Default)
Selection Option
UPPER LEFT PANE
UPPER RIGHT PANE
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Selection Option
UPPER LEFT
UPPER RIGHT
LOWER LEFT
LOWER RIGHT
OFF (Default)
UPPER LEFT
UPPER RIGHT
LOWER LEFT
LOWER RIGHT
