Standard Accessories

Item
Standard accessories
TVM Options
Item
TVM-VTM-ACV-2
TVM-VTM-SDI-S
TVM-VTM-S2H-F
TVM-VTM-SDI-H
TVM-VTM-EYE-S
TVM-VTM-ES2H-F
TVM-VTM-EYE-H
TVM-VTM-JEM
TVM-VTM-3GB
TVM-VTM-ASI
TVM-VTM-DLK
Specifications
Specification
•
TVM Installation and Operation Handbook
•
Breakout connector for GPI/TALLY/LTC/CLOCK
• One rack mounting kit
•
One power cord
•
DVI to VGA adapter
Specification
Two (2) looping analog composite video inputs for NTSC or PAL
format
Two (2) looping inputs for SMPTE 259M-C (SD-SDI) with auto detect
and monitor output; replaces standard A/B inputs or C/D inputs
Software Feature Upgrade to add SMPTE 292M (HD-SDI) to TVM-
VTM-SDI-S
Two (2) looping inputs for SMPTE 292M (HD-SDI) or SMPTE 259M-C
(SD-SDI) with auto detect and monitor output; replaces standard A/B
inputs or C/D inputs
Two (2) looping inputs for SMPTE 259M-C (SD-SDI) with auto detect,
EYE pattern and monitor output; replaces standard A and B inputs
(must be used as inputs A and B [Only one per unit])
Software Feature Upgrade to add SMPTE 292M (HD-SDI) to TVM-
VTM-EYE-S
Two (2) looping inputs for SMPTE 292M (HD-SDI) or SMPTE 259M-C
(SD-SDI) with auto detect, EYE pattern and monitor output. Replaces
standard A and B inputs. Must be used as inputs A and B. (Only one
per unit).
Two looping inputs for SMPTE 292M (HD-SDI) or SMPTE 259M-C
(SD-SDI), auto detect with EYE pattern and monitor output with
advanced jitter analysis and monitor output. Must be used as inputs A
and B. (Only one per unit).
Input module which accepts two active-looping triple-rate (2.97 Gb/s,
1.485 Gb/s, and 270 Mb/s) HD-SDI or SD-SDI input signals for
display and analysis. One triple-rate SDI monitor output is switchable
from following the selected SDI video input to becoming an internal
test generator that displays color bars, pathological checkfield, and
color bars with motion. The Test Signal Generator is free-running (no
genlock capability). Embedded audio and Video Payload ID per
SMPTE 352M-2002 ancillary data insertion is supported. Supplies
additional support for dual-link HD-SDI 12-bit YC
formats. Requires TVM-40
Two (2) passive-looping DVB-ASI and SMPTE310 inputs. It accepts
two independent MPEG streams and analyzes one selected stream
for compliance to measurement guidelines of ETSI TR-101-290
(ETR-290) first, second, and third priority standards.
Expands the Dual link capability of the TVM-VTM-SDI-H, TVM-VTM-
EYE-H, TVM-VTM-JEM, and to include 10-bit RGB (4:4:4) and
RGB+A (4:4:4:4) formats. Requires TVM-40.
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
C and RGB video
