Tab/Tab Details
Clicking the Tab at the top of the screen will link to the appropriate tab page, as shown
in the example in Figure 6-1. Table 6-2 describes the fields shown in the Tab/Tab
Details section.
Table 6-2. Tab/Tab Details Description
Key Field
1 WEB FUNCTION TABS
2 ABOUT
3 GPIO
4 SYSTEM
5 TIMECODE ALARMS
6 ANALOG ALARMS
7 DIGITAL ALARMS
8 AUDIO ALARMS
9 TS ALARMS
10 TAB PAGE
208
External Control
Description
Click the Tab to access the appropriate Tab page for the
specified tab function.
The ABOUT tab is a read-only screen that contains the
Firmware Version, VPR ID, Slot 1 ID, Slot 2 ID, Audio ID,
Display firmware version, Panel version, RCU version, and
serial number information. This is similar to the ABOUT
screen described on page 186.
The GPIO tab displays the GPI Alarm Rename screen. All 9
GPI Alarm names can be changed on this screen. There is a
16-character limit for each GPI Alarm Name.
The System Screen is used to rename the Input Source IDs
and indicate the number of current monitored alarms. The
Input Source ID is described on page 167.
The number of current monitored alarms field is a read-only
display that indicates the number of active alarms for the
selected input. This field does not indicate the alarms for all
the inputs at the same time.
The Time Code Alarms Screen indicates the Alarm Enable
and Parameter Settings field for each Time Code Alarm.
The Enable Field is set with a "0" for Disable Alarm or a "1"
for Enable Alarm. See Table 4-10 on page 155 for the list of
alarm parameters.
The Analog Alarms Screen indicates the Alarm Enable and
Parameter Settings field for each Analog Video Alarm. The
Enable Field is set with a "0" for Disable Alarm or a "1" for
Enable Alarm. See Table 4-9 on page 149 for the list of
alarm parameters.
The Analog Alarms Screen indicates the Alarm Enable and
Parameter Settings field for each Digital Video Alarm. The
Enable Field is set with a "0" for Disable Alarm or a "1" for
Enable Alarm. See Table 4-8 on page 144 for the list of
alarm parameters.
The Audio Alarms Screen indicates the Alarm Enable and
Parameter Settings field for each Audio Alarm. The Enable
Field is set with a "0" for Disable Alarm or a "1" for Enable
Alarm. See the A
3
and A -OPT 3/5-TL Installation and Operation Handbook for
the complete list of audio alarms for the selected option.
The TS Alarms Screen indicates the Alarm Enable and
Parameter Settings field for each TS Alarm. The Enable
Field is set with a "0" for Disable Alarm or a "1" for Enable
Alarm. See Table 4-11 on page 156 for the list of alarm
parameters
Lists all the fields associated with the selected tab. To see
the latest values of the instrument for the selected TAB
PAGE press the F5 button to refresh the screen.
