In the SWEEP group, press the H button to select one of the horizontal sweep
modes. Also, press the H button to step through each component in a signal. The
Components that are utilized with the H button can be selected and deselected in
the COMPONENT SEQUENCE pane menu. When one to four components are selected,
press the H button to view 1H (1 Horizontal or 5.0 µs when one component is shown).
With one component selected, press the H button to toggle between viewing one single
component H waveform and multiple component H waveforms (with blanking turned off
two simultaneous component H waveforms are used to view any ancillary data).
When two components are selected in the COMPONENT SEQUENCE pane menu, press
the H button to view 1H or 2H (2 Horizontal or 10.0 µs when 2 simultaneous
components are shown). When three components are selected in the COMPONENT
SEQUENCE pane, press the H button to view 1H or 3H (3 Horizontal or 15.0 µs when
three simultaneous components are shown). When four components are selected in the
COMPONENT SEQUENCE pane, press the H button to view 1H or 4H (4 Horizontal or
20.0 µs when four simultaneous components are shown in YRGB).
NOTE: Vertical Sweep is disabled when in R-Y mode (ACV only).
Also in the SWEEP group, press the V button to select one of the vertical
sweep modes. The Components that are utilized with the V button can be
selected and deselected in the COMPONENT SEQUENCE pane menu. A/B
mode will show only one component from the selection of R, G, or B when in 2V
mode. When one to three components are selected, press the V button to view 1V
(1 Vertical when one component is shown). With one component selected, press the V
button to toggle between viewing one single component V waveform and two multiple
component V waveforms (with blanking turned off two simultaneous component V
waveforms are used to view any ancillary data).
When two components are selected in the COMPONENT SEQUENCE pane menu,
press the V button to view 1V or 2V (2 Vertical when 2 simultaneous components are
shown). When three components are selected in the COMPONENT SEQUENCE pane
menu, press the V button to view 1V or 3V (3 Vertical for SDI when three
simultaneous components are shown). When four components are selected in the
COMPONENT SEQUENCE pane menu, press the V button to view 1V or 4V (4
Vertical for SDI when four simultaneous components are shown).
Press the MAG button to change the horizontal magnification or to turn the
magnification OFF.
