CC4, T1 to T4, and 708 (which is HD only) Service 1 to 7. For more information on
Closed Captioning, see Closed Caption on page 80.
XDS
Located in the upper-left corner of the picture display is the Extended Data Services
(XDS) display when it is enabled in the PICTURE SETUP menu. The
Picture Setup/XDS menu is used to enable and disable XDS along with selecting the
information for line 6.
When XDS is selected, XDS data is decoded. There are five fixed lines (ID number,
Length of Time Elapsed, Program Name, Channel Info Network Name, and Content
Advisory), and one selectable line. Use the UP/DOWN NAVIGATION buttons to
select an item for the XDS.
The XDS selections are shown in Table 4-19. The bold items are always shown and
cannot be changed on the XDS display. All items are selectable except CHANNEL
INFO NETWORK NAME are available for line 6. For more information on XDS see
information on page 108.
Table 4-19. XDS Line Selections
Selection
ID NUMBER
LENGTH ELAPSED TIME
PROGRAM NAME
CHANNEL INFO NETWORK
NAME*
TYPE
CONTENT ADVISORY
AUDIO SERVICES
CAPTION SERVICES
COPY MANAGEMENT
ASPECT RATIO
COMPOSITE PACKET 1
COMPOSITE PACKET 2
DESCRIPTION
FUTURE ID NUMBER
FUTURE LENGTH ELAPSED
TIME
FUTURE PROGRAM NAME
FUTURE TYPE
172
Global Setup Menu Functions
Selection Option
FUTURE CONTENT
ADVISORY
FUTURE AUDIO SERVICES
FUTURE CAPTION SERVICES
FUTURE COPY
MANAGEMENT
FUTURE ASPECT RATIO
FUTURE COMPOSITE
PACKET 1
FUTURE COMPOSITE
PACKET 2
FUTURE DESCRIPTION
PSIP MINOR CHANNEL
PSIP EVENT NUMBER
PSIP EVENT START
PSIP EVENT DURATION
PSIP PROGRAM NAME
PSIP PROGRAM TYPE
PSIP CONTENT ADVISORY
PSIP AUDIO SERVICES
PSIP CAPTION SERVICES
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Selection Option
PSIP STRUCTURE CONTROL
PSIP EIT DESCRIPTOR
PSIP DATA CARRIAGE
CHANNEL INFO CALL
LETTERS
CHANNEL INFO TAPE DELAY
CHANNEL INFO TSID
MISC TIME OF DAY
MISC IMPULSE CAPTURE ID
MISC SUPPLEMENTAL DATA
LOCATION
MISC TIME ZONE
OUT OF BAND CHANNEL
CHANNEL MAP POINTER
CHANNEL MAP HEADER
CHANNEL MAP PACKET
NATIONAL WEATHER SVC
CODE
NATIONAL WEATHER SVC
MSG
-
