DVI-I Output Specifications
Item
Digital levels
R, G, B levels
Pixel rate
Analog R,G,B impedance
Horizontal sync
Vertical sync
Display accuracy
Connector
Audio Options
Item
Inputs (analog)
Maximum input level
Input connector
Impedance
Inputs (digital)
Input connectors
Impedance
Outputs (analog)
Output level
Output connector
Impedance
Signal to noise
Outputs (digital)
Output connector
Impedance
218
Specifications
Specification
Per DDWG DVI rev 1
Selectable 0.7 or 1V p-p, nominal
65 Mp/s
75Ω
Negative TTL pulse @ 48,363 Hz ± 1%
Negative TTL pulse @ 60.004 Hz ± 1%
•
± 1% waveform
•
± 1° vector
• ± 37 ns Timing Digital
•
± 300 ns Timing Analog
29-pin DVI-I, female
Specification
Eight monophonic or four stereo channels, balanced or unbalanced
+24 dBu
37-pin, D-sub, male
> 20kΩ
Four AES/EBU serial digital pairs with input expansion option to
eight. Sixteen embedded audio channels, one Dolby® E or AC-3
stream
Four or eight, BNC, female
75Ω
Eight monophonic or four stereo channels, balanced or unbalanced,
follows selected audio input; Dolby inputs produce a two channel mix
down and/or full eight channel decode
+24 dBu max
+6 to –50 dB adjustable
For digital audio, -20 dBFS produces a +4 dBu analog output level
37-pin D-sub, male, shared with inputs
10Ω unbalanced or 20Ω balanced, nominal
100 dB (relative to signal level out of +24 dBu), typical
4 AES/EBU and one Dolby
embedded in the selected digital video source
Four shared with input
75Ω, BNC, female
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
® ®
Digital, Dolby E, or AES stream
