Table 3-19. Horizontal Magnification Conditions

Horizontal Mag
x1 (1 ns or 250 ps)
x5 (0.20 ns or 50 ps)
x10 (0.10 ns or 25 ps)
Press the ZOOM button to zoom around the reference graticule. At each zoom
position, the graticule scale and eye pattern displays expand to provide more
resolution around the zoom point.
For the Jitter Waveform display, press the ZOOM button to toggle the Jitter gain from
OFF (2 UI p-p) to ON (1 UI p-p).
For the Jitter Frequency display, press the ZOOM button to toggle the Frequency Sweep
between 0 – 5 MHz or 0 – 1 MHz.

Eye Pattern Cursor Selections

Cursors are available for precise measurement of waveform voltage and
waveform time. Press the CURS button on the front panel to enable the
cursors for the selected pane. The Time Cursor indication is in the
lower-right portion, and the amplitude cursor indication is in the lower-left of the
screen as shown in Figure 3-27.
General Operation
Format Displayed
SD/HD
3 eye displayed
SD
10 eyes displayed
HD
20 eyes displayed
SD/HD
3/5 eye displayed
SD
2 eyes displayed
HD
4 eyes displayed
SD/HD
3/10 eye displayed
SD
1 eye displayed
HD
2 eyes displayed
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Number of Eyes Displayed
57
