Component Sequence (SDI Signals only)

Select to enable the component Y, C
HD Format menu; Y, R, G, and B, when YRGB is selected in the SD or HD FORMAT
menu.

Center Waveform

Press the ENT button to activate the Center Waveform selection. Once ENT is pressed,
the waveform returns to the center of the waveform graticule.

Waveform Setup

Press the ENT button to access the global Waveform setup menu. For more
information on the global Waveform Setup menu see Section 4.
Utilizing the EYE Display (TVM-VTM-EYE-H,
TVM9100PKG-EH, TVM9100PKG-ES, TVM9140PKG-EH,
TVM9140PKG-ES)
NOTE: Available for Inputs A and B only.
The Eye Pattern display is created by sampling the serial digital signal with the
recovered serial clock. The Eye Pattern display is used to measure signal amplitude,
jitter, rise time, and other irregularities. Measurement of the transition widths is done
by manually setting the cursors on the transition limits of the display and reading the
offset in picoseconds (ps). The amount of jitter can also be estimated from the bar
display above the Eye Pattern display. Amplitude is similarly measured using cursors.
To access the Eye Pattern display, press the EYE function button on the front panel.
The Eye Pattern Display Diagram is displayed in Figure 3-15 and described in Table
3-11.
