Videotek TVM9100PKG Installation And Operation Handbook page 240

Video Input Specifications: HD-SDI/SD-SDI Option
Item
Monitor output data rate
Monitor output connector
Monitor output level
Video Input Specifications: SD-SDI Option
Item
Digital inputs
Data rate
Connectors
Level
Input cable equalization
Return loss
Monitor output
Monitor output data rate
Monitor output connector
Monitor output level
Video Input Specifications: Analog Option
Item
Analog inputs (C and D only)
Signal level
Input impedance
Return loss
Reference inputs
Inputs
Levels
Impedance
EYE and Jitter/Frequency Patterns
Item
Eye display input
EYE display types
EYE horizontal mag
216
Specifications
Specification
270 Mb/s and 1.485 Gb/s
BNC
800 mV, nominal
Specification
Two (2) SMPTE 259-MC inputs, auto detect 525/59.94 and 625/50
270 Mb/s auto detect
Hi-Z looping
4 BNCs, active looping, option EYE-S
800 mV, nominal source amplitude
Up to 250 meters of Belen 8281 at 270 Mb/s
≤ -25 dB 100 kHz to 270 MHz
Follows the selected digital input
270 Mb/s
BNC
800 mV, nominal
Specification
Two (2) NTSC/PAL composite video auto detect
1V p-p
Hi-Z, looping
≤ -45 dB 100 kHz to 5 MHz
Analog Blackburst, NTSC/PAL composite video, Tri-level sync auto
detect per SMPTE 274M
286 mV p-p ± 6 dB (Blackburst NTSC)
300 mV p-p ± 6 dB (PAL sync and burst)
600 mV p-p ± 3 dB (Tri level Sync)
Selectable Hi-Z looping or 75Ω terminating
Specification
Displays pre-equalized waveforms
• SD: 3 eye or 10 eye
•
HD: 3 eye or 20 eye
•
x1 - SD/HD = 3 eye displayed
- SD = 10 eyes displayed
