Table 4-8. Video Alarms, Digital Menu
Selection
CRC- HD
EDH - SD
LETTERBOX - SD
PILLAR BOX - HD
148
Global Setup Menu Functions
Selection Option Selection Option
WSS (WIDE ENABLE
SCREEN
SIGNALING) NOT
DETECTED
DURATION
XDS NOT ENABLE
DETECTED
DURATION
XDS NOT ENABLE
UPDATING
DURATION
ENABLE OFF (Default)
ON
DURATION 0 TO 60 Seconds (2
Seconds is Default)
ENABLE OFF (Default)
ON
DURATION 0 TO 60 Seconds (2
Seconds is Default)
TOP BORDER ENABLE
END OF TOP BORDER
525
END OF TOP BORDER
625
BOTTOM BORDER ENABLE
START OF BOTTOM
BORDER 525
START OF BOTTOM
BORDER 625
THRESHOLD 10 TO 350 mV (286 mV
is Default)
DURATION 0 TO 60 Seconds (2
Seconds is Default)
LEFT BORDER ENABLE
END OF LEFT BORDER
RIGHT BORDER ENABLE
START OF RIGHT
BORDER
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Selection Option
OFF (Default)
ON
10 TO 600 SECONDS
(240 SEC is Default)
OFF (Default)
ON
10 TO 600 SECONDS
(240 SEC is Default)
OFF (Default)
ON
10 TO 600 SECONDS
(240 SEC is Default)
-
-
-
-
-
-
-
NTSC LINES:
+21 TO +139
(21 is Default)
PAL LINES:
+19 TO +159
(19 is Default)
-
NTSC LINES:
+140 TO +262
(140 is Default)
PAL LINES:
+160 TO +312
(160 is Default)
-
-
-
+1 TO +860
(1 is Default)
-
+861 TO +1920
(1920 is Default)
