Control Specifications
Item
GPI
GPO
Connector
Input impedance
Alarm output
Maximum relay current
External router control
Peripheral interface
Connector
Display Specifications
Item
General
Waveform
Sweep time base
Waveform accuracy
Eye (optional)
Sweep time base
Filters
Vector
Vector accuracy
Gamut
Audio (Optional)
Time Code Specifications
Item
Input
Display
Specifications
Specification
Nine total with four input and five preset recall selections or
individually user configured as alarm input
Two alarms, user configured
26-pin HD (high density) D-sub, female
10 kΩ returned to +5 VDC
Relay closure
350 mA @ 30 VDC
One RJ-11 female, for use with Harris RS-12 series routers for future
expansion
USB 1.1 supporting storage devices, and keyboard
USB 1.1, Type A, female
Specification
A quadrant display for viewing an input on up to four different
displays as picture, waveform, vector, audio, alarm status, timing,
optional eye pattern, simultaneously or individually as a full screen
display of each separately. Additional data analyzer display for pixel
analysis. Also, view multiple waveform and vectors of the same or
different inputs.
Composite; YC C or RGB, parade/overlay of like formats
B R
•
1H or 2H with x1, x5, and x10 horizontal magnification
•
1V or 2V with x1, x5, and x25 horizontal magnification
≤ 1%
Display Eye or waveform individually or paraded
Overlay or 10 Eye (SD), 20 Eye (HD)
10, 100 Hz, 1 kHz
R-Y vs. B-Y for Analog C
≤ 1°
Encoded or RGB gamut displays with upper and lower limit selection
2, 4, 6, or 8 channels displayed simultaneously
Specification
• LTC via back panel connector
•
Ancillary Time Code (HD only)
• DVITC extracted from SD inputs
• Displayed directly
•
Used to set internal clock
