Table 7-1. TVM Series: Problems, Causes, and Solutions
Problem/Symptom
Picture width not correct
Input switches by itself
No communications on remote
(RCU) port
No communications on
Ethernet port
If the problem still exists after troubleshooting the TVM, see Section 1, "Service
Support," for further instructions.
Troubleshooting
Possible Cause
The aspect ratio is not set
correctly.
The router control is on.
The baud rate is not correct.
The IP address is incorrect.
Incorrect Ethernet cable.
TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Solution or Explanation
Change aspect ratio in the setup
menu.
Turn off router control in the setup
menu.
Select the proper RCU baud rate.
Provide the correct IP address in
setup menu.
For a direct connection, use a
crossover cable. For a network
connection, use a standard
Ethernet cable.
