4. Defining Filter Slides (infinite® F200 only)
4.2.2

Filter Types

STOP
®
infinite F200:
Filter Slide - Direction of Light
Direction of light
(Excitation)
56
There are two types of filters. It is important that light travels through
both types of filter in the correct direction. Before inserting a new filter
carefully consider the filter and the direction of light through
1. Filters with an arrow on the side:
Light must travel in the direction of the arrow.
2. Filters without an arrow on the side:
Direction of light
Correct
The end of the filter with the metal lip must face away from the light source.
Instructions for Use for infinite® 200 No. 30017581 Rev. No. 1.4
Caution
the filter slide.
Direction of light
Incorrect
(Emission)
2008-07
