5. Optical System
5.5.3

Cuvette types

Cuvette Type
Standard cuvettes
Semi-macro
cuvettes
Micro cuvettes
Ultra-micro
cuvettes
STOP
STOP
∗
Hellma GmbH & Co. KG, Germany; www.hellma-worldwide.com
80
The cuvette port is compatible with the following cuvettes:
Maximum Height
Width x Depth
(including lid)
12.5 x 12.5 mm
12.5 x 12.5 mm
12.5 x 12.5 mm
12.5 x 12.5 mm
Cuvettes with a measurement window < 2 mm (diameter) cannot be used.
Always use a valid filling volume. Make sure that the liquid level in the
cuvette exceeds 20 mm (height). Otherwise the light path in the cuvette
might not be filled completely with liquid which can lead to wrong
The cuvette port of the infinite
cuvettes with a measurement window < 2 mm (diameter)
and a center height below 15 mm.
Instructions for Use for infinite® 200 No. 30017581 Rev. No. 1.4
Filling Volume
55 mm 2 ml
55 mm 1 ml
55 mm 0.5 ml
55 mm 100 µl
Caution
measurement results.
Caution
®
M200 cannot be used for
Example
Hellma 110 QS,
∗
10 mm
Hellma 108-QS,
∗
10 mm
Hellma 104.002
∗
QS, 10 mm
Hellma 105.202,
∗
10 mm
