FC 300 Design Guide
Parameters: DeviceNet CAN
Fieldbus
10-** DeviceNet CAN Fieldbus
Parameter group for DeviceNet CAN fieldbus pa-
rameters.
10-0* Common Settings
Parameter group for configuring common settings
for CAN fieldbus options.
10-00
CAN Protocol
Value:
CANopen
DeviceNet
Function:
View the active CAN protocol.
NB!
The options depend on installed op-
tion.
10-01
Baud Rate Select
Value:
10 Kbps
20 Kbps
50 Kbps
100 Kbps
125 Kbps
250 Kbps
500 Kbps
Function:
Select the fieldbus transmission speed. The selec-
tion must correspond to the transmission speed of
the master and the other fieldbus nodes.
10-02
MAC ID
Value:
0 - 127
Function:
Selection of station address. Every station con-
nected to the same network must have an unam-
biguous address.
factory setting
200
How to Programme
[0]
[1]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
63
()
display text
[]
value for use in communication via serial communication port
MG.33.B7.02 - VLT is a registered Danfoss trademark
10-05
Readout Transmit Error Counter
Value:
0 - 255
Function:
View the number of CAN control transmission er-
rors since the last power-up.
10-06
Readout Receive Error Counter
Value:
0 - 255
Function:
View the number of CAN control receipt errors
since the last power-up.
10-07
Readout Bus Off Counter
Value:
0 - 255
Function:
View the number of Bus Off events since the last
power-up.
10-1* DeviceNet
Parameters specific to the DeviceNet fieldbus.
10-10
Process Data Type Selection
Value:
Instance 100/150
Instance 101/151
Instance 20/70
Instance 21/71
Function:
Select the Instance (telegram) for data transmis-
sion. The Instances available are dependent upon
the setting of par. 8-10 Control Word Profile.
When par. 8-10 is set to [0] FC profile, par. 10-10
options [0] and [1] are available.
When par. 8-10 is set to [5] ODVA, par. 10-10
options [2] and [3] are available.
Instances 100/150 and 101/151 are Danfoss-spe-
cific. Instances 20/70 and 21/71 are ODVA-spe-
cific AC Drive profiles.
For guidelines in telegram selection, please refer
to the DeviceNet Operating Instructions.
Note that a change to this parameter will be exe-
cuted immediately.
0
0
0
[0]
[1]
[2]
[3]
