FC 300 Design Guide
16-** Data Readouts
Par. Parameter description
No. #
16-0* General Status
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference %
16-03 Status Word
16-05 Main Actual Value [%]
16-09 Custom Readout
16-1* Motor Status
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
16-13 Frequency
16-14 Motor Current
16-15 Frequency [%]
16-16 Torque [Nm]
16-17 Speed [RPM]
16-18 Motor Thermal
16-19 KTY sensor temperature
16-20 Motor Angle
16-22 Torque [%]
16-3* Drive Status
16-30 DC Link Voltage
16-32 Brake Energy /s
16-33 Brake Energy /2 min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-36 Inv. Nom. Current
16-37 Inv. Max. Current
16-38 SL Controller State
16-39 Control Card Temp.
16-40 Logging Buffer Full
16-5* Ref. & Feedb.
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
16-53 Digi Pot Reference
How to Programme
Default value
(SR = Size Related)
0
0.000
0.0 %
0
0.00 %
0.00
0.00 kW
0.00 hp
0.0 V
0.0 Hz
0.00 A
0.00 %
0.0 Nm
0 RPM
0 %
0 °C
0
0 %
0 V
0.000 kW
0.000 kW
0 °C
0 %
SR
SR
0
0 °C
[0] No
0.0
0.0
0.000
0.00
MG.33.B7.02 - VLT is a registered Danfoss trademark
4-set-up FC 302 Change
only during
opera-
tion
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
Conver- Type
sion in-
dex
0 V2
-3 Int32
-1 Int16
0 V2
-2 N2
-2 Int32
1 Int32
-2 Int32
Uint1
-1 6
Uint1
-1 6
-2 Int32
-2 N2
-1 Int16
67 Int32
0 Uint8
100 Int16
Uint1
0 6
0 Int16
Uint1
0 6
Uint3
0 2
Uint3
0 2
100 Uint8
0 Uint8
Uint3
-2 2
Uint3
-2 2
0 Uint8
100 Uint8
- Uint8
-1 Int16
-1 Int16
-3 Int32
-2 Int16
