16-** Data Read-outs
Parameter group for data read-outs, e.g. actual
references, voltages, control, alarm, warning and
status words.
16-0* General Status
Parameters for reading the general status, e.g.
the calculated reference, the active control word,
status.
16-00 Control Word
Value:
0 - FFFF
Function:
View the Control word sent from the frequency
converter via the serial communication port in hex
code.
16-01 Reference [Unit]
Value:
-999999.000 - 999999.000
Function:
View the present reference value applied on im-
pulse or analog basis in the unit resulting from the
configuration selected in par. 1-00 (Hz, Nm or
RPM).
16-02 Reference %
Value:
-200.0 - 200.0 %
Function:
View the total reference. The total reference is the
sum of digital, analog, preset, bus, and freeze ref-
erences, plus catch-up and slow-down.
16-03 Status Word
Value:
0 - FFFF
Function:
View the Status word sent from the frequency
converter via the serial communication port in hex
code.
factory setting
How to Programme
0.000
0.0%
() display text []
MG.33.B7.02 - VLT is a registered Danfoss trademark
16-05 Main Actual Value [%]
Value:
0 - 0 N/A
Function:
View the two-byte word sent with the Status word
to the bus Master reporting the Main Actual Value.
Please refer to the VLT® AutomationDrive FC 300
Profibus Operating Instructions MG.33.CX.YY for a
detailed description.
16-1* Motor Status
Parameters for reading the motor status values.
0
16-10 Power [kW]
Value:
0.0 - 1000.0 kW
Function:
View the motor power in kW. The value shown is
calculated on the basis of the actual motor voltage
and motor current. The value is filtered, and
therefore approx. 1.3 seconds may pass from
when an input value changes to when the data
read-out values change.
16-11 Power [hp]
Value:
0.00 - 1000.00 hp
Function:
View the motor power in hp. The value shown is
calculated on the basis of the actual motor voltage
and motor current. The value is filtered, and
therefore approx. 1.3 seconds may pass from
when an input value changes to when the data
read-out values change.
16-12 Motor Voltage
Value:
0.0 - 6000.0 V
Function:
0
View the motor voltage, a calculated value used
for controlling the motor.
value for use in communication via serial communication port
N/A
0.0kW
0.00hp
0.0V
