FC 300 Design Guide
Function:
Select Reset SLC [1] to reset all group 13 param-
eters (13-*) to default settings.
Select *Do not reset SLC [0] to retain the pro-
grammed settings in all group 13 parameters (13-
*).
13-1* Comparators
Comparators are used for comparing continuous
variables (i.e. output frequency, output current,
analog input etc.) with fixed preset values. Com-
parators are evaluated once in each scan interval.
Use the result (TRUE or FALSE) directly to define
an event (see par. 13-51), or as boolean input in
a logic rule (see par. 13-40, 13-42, or 13-44). All
parameters in this parameter group are array pa-
rameters with index 0 to 3. Select index 0 to pro-
gramme Comparator 0, select index 1 to pro-
gramme Comparator 1, and so on.
13-10 Comparator Operand
Array [6]
Value:
DISABLED
Reference
Feedback
Motor speed
Motor current
Motor torque
Motor power
Motor voltage
DC-link voltage
Motor thermal
VLT thermal
Heat sink temp.
Analog input AI53
Analog input AI54
Analog input AIFB10
Analog input AIS24V
Analog input AICCT
Pulse input FI29
Pulse input FI33
Alarm number
Counter A
Counter B
factory setting
208
How to Programme
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[17]
[18]
[19]
[20]
[30]
[31]
() display text [] value for use in communication via serial communication port
MG.33.B7.02 - VLT is a registered Danfoss trademark
Function:
Select the variable to be monitored by the com-
parator.
*False [0] (default setting) enters the fixed value
of FALSE in the logic rule.
True [1]. enters the fixed value TRUE in the logic
rule.
Running [2] See parameter group 5-3* for further
description.
In range [3] See parameter group 5-3* for further
description.
On reference [4] See parameter group 5-3* for
further description.
Torque limit [5] See parameter group 5-3* for
further description.
Current limit [6] See parameter group 5-3* for
further description.
Out of current range [7] See parameter group
5-3* for further description.
Below I low [8] See parameter group 5-3* for fur-
ther description.
Above I high [9] See parameter group 5-3* for
further description.
Below frequency low [11] See parameter group
5-3* for further description.
Above frequency high [12] See parameter group
5-3* for further description.
Thermal warning [16] See parameter group 5-3*
for further description.
Mains voltage out of range [17] See parameter
group 5-3* for further description.
Reversing [18] See parameter group 5-3* for fur-
ther description.
Warning [19] See parameter group 5-3* for fur-
ther description.
Alarm (trip) [20] See parameter group 5-3* for
further description.
Alarm (trip lock) [21] See parameter group 5-3*
for further description.
Comparator 0 [22] Use the result of comparator 0
in the logic rule.
Comparator 1 [23] Use the result of comparator 1
in the logic rule.
Comparator 2 [24] Use the result of comparator 2
in the logic rule.
Comparator 3 [25] Use the result of comparator 3
in the logic rule.
Logic rule 0 [26] Use the result of logic rule 0 in
the logic rule.
Logic rule 1 [27] Use the result of logic rule 1 in
the logic rule.
