FC 300 Design Guide
0-03 Regional Settings
Value:
International
US
Function:
Select International [0] to set par.1-20 Motor
Power units to kW and the default value of par.
1-23 Motor Frequency to 50 Hz. Select US [1] to
set par.1-21 Motor Power units to HP and the de-
fault value of par. 1-23 Motor Frequency to 60 Hz.
This parameter cannot be adjusted while the mo-
tor is running.
Operating State at Power-up
0-04
(Hand)
Value:
Resume
Forced stop, ref=old
Forced stop, ref = 0
Function:
Select the operating mode upon reconnection of
the frequency converter to mains voltage after
power down in Hand (local) operation mode.
SelectResume [0] to restart the frequency con-
verter maintaining the same local reference and
the same start/stop settings (applied by [START/
STOP]) as before the frequency converter was
powered down.
Select Forced stop, use saved reference [1] to re-
start the frequency converter with a saved local
reference, after mains voltage reappears and af-
ter pressing [START].
Select Forced stop, set reference to 0 [2] to reset
the local reference to 0 upon restarting the fre-
quency converter.
0-1* Set-up Operations
Define and control the individual parameter set-
ups.
0-10 Active Set-up
Value:
Factory setup
Set-up 1
Set-up 2
Set-up 3
Set-up 4
factory setting
How to Programme
[0]
[1]
[0]
[1]
[2]
[0]
[1]
[2]
[3]
[4]
() display text []
MG.33.B7.02 - VLT is a registered Danfoss trademark
Active set-up
Function:
Select the set-up to control the frequency con-
verter functions.
Factory Set-up [0] cannot be changed. It contains
the Danfoss data set, and can be used as a data
source when returning the other set-ups to a
known state.
Set-up 1 [1] to Set-up 4 [4] are the four separate
parameter set-ups within which all parameters
can be programmed.
Select Active Set-up [9] for remote selection of
set-ups using digital inputs and the serial com-
munication port. This set-up uses the settings
from par. 0-12 'This option linked to'. Stop the
frequency converter before making changes to
open loop and closed loop functions.
Use par. 0-51 Set-up copy to copy a set-up to one
or all other set-ups. Stop the frequency converter
before switching between set-ups where parame-
ters marked 'not changeable during operation'
have different values. To avoid conflicting settings
of the same parameter within two different set-
ups, link the set-ups together using par. 0-12 This
set-up linked to. Parameters which are 'not
changeable during operation' are marked FALSE
in the parameter lists in the section Parameter
Lists.
0-11 Edit Set-up
Value:
Factory setup
Set-up 1
Set-up 2
Set-up 3
Set-up 4
Active Set-up
Function:
Select the set-up to be edited (i.e. programmed)
during operation; either the active set-up or one
of the inactive set-ups.
Factory set-up [0] cannot be edited but it is useful
as a data source to return the other set-ups to a
known state. Set-up 1 [1] to Set-up 4 [4] can be
edited freely during operation, independently of
the active set-up. The Active set-up [9] can also
be edited during operation. Edit the chosen set-up
value for use in communication via serial communication port
[9]
[0]
[1]
[2]
[3]
[4]
[9]
