Select Over Voltage Control function in
par. 2-17
Connect a brake resistor
Extend the ramp time
Activate functions in par. 2-10
Increase par. 14-26
Selecting OVC function will extend the ramp
times.
Alarm/warning limits:
FC 300 Series 3 x 200-240 V
AC
Undervoltage
Voltage warning low
Voltage warning
high (w/o brake - w/
brake)
Overvoltage
The voltages stated are the intermediate circuit volt-
age of the FC 300 with a tolerance of ± 5 %. The
corresponding mains voltage is the intermediate cir-
cuit voltage (DC-link) divided by 1.35
WARNING/ALARM 8
DC under voltage:
If the intermediate circuit voltage (DC) drops be-
low the "voltage warning low" limit (see table
above), the frequency converter checks if 24 V
backup supply is connected.
If no 24 V backup supply is connected, the fre-
quency converter trips after a given time depend-
ing on the unit.
To check whether the supply voltage matches the
frequency converter, see General Specifications.
WARNING/ALARM 9
Inverter overloaded:
The frequency converter is about to cut out be-
cause of an overload (too high current for too
long). The counter for electronic, thermal inverter
protection gives a warning at 98% and trips at
100%, while giving an alarm. You cannot reset the
frequency converter until the counter is below
90%.
The fault is that the frequency converter is over-
loaded by more than nominal current for too long.
WARNING/ALARM 10
Motor ETR over temperature:
According to the electronic thermal protection
(ETR), the motor is too hot. You can choose if you
want the frequency converter to give a warning or
an alarm when the counter reaches 100% in par.
296
Troubleshooting
3 x 380-500 V
AC
[VDC] [VDC]
185 373
205 410
390/405 810/840
410 855
