9-** Profibus
Parameter group for all Profibus-specific parame-
ters.
9-00 Setpoint
Value:
0-65535
Function:
This parameter receives cyclical reference from a
Master Class 2. If the control priority is set to Mas-
ter Class 2, the reference for the frequency con-
verter is taken from this parameter, whereas the
cyclical reference will be ignored.
9-07 Actual Value
Value:
0-65535
Function:
This parameter deliveres the MAV for a Master
Class 2. The parameter is valid if the control pri-
ority is set to Master Class 2.
9-15 PCD Write Configuration
Array [10]
Value:
None
3-02 Minimum Reference
3-03 Maximum Reference
3-12 Catch Up/Slow Down Value
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-51 Ramp 2 Ramp Up Time
3-52 Ramp 2 Ramp Down Time
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Time
4-11 Motor Speed Low Limit [RPM]
4-13 Motor Speed High Limit [RPM]
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
7-28 Minimum Feedback
7-29 Maximum Feedback
8-90 Bus Jog 1 Speed
8-91 Bus Jog 2 Speed
factory setting
194
How to Programme
() display text [] value for use in communication via serial communication port
MG.33.B7.02 - VLT is a registered Danfoss trademark
16-80 Fieldbus CTW 1
16-82 Fieldbus REF 1
34-01 PCD 1 Write to MCO
34-02 PCD 2 Write to MCO
34-03 PCD 3 Write to MCO
34-04 PCD 4 Write to MCO
34-05 PCD 5 Write to MCO
34-06 PCD 6 Write to MCO
0
34-07 PCD 7 Write to MCO
34-08 PCD 8 Write to MCO
34-09 PCD 9 Write to MCO
34-10 PCD 10 Write to MCO
Function:
Select the parameters to be assigned to PCD 3 to
10 of the telegrams. The number of available
PCDs depends on the telegram type. The values in
PCD 3 to 10 will then be written to the selected
parameters as data values. Alternatively, specify
0
a standard Profibus telegram in par. 9-22.
9-16 PCD Read Configuration
Array [10]
Value:
None
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference %
16-03 Status Word
16-04 Main Actual Value [Unit]
16-05 Main Actual Value [%]
16-09 Custom Readout
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
16-13 Frequency
16-14 Motor Current
16-16 Torque
16-17 Speed [RPM]
16-18 Motor Thermal
16-19 KTY Sensor Temperature
16-21 Phase Angle
16-30 DC Link Voltage
16-32 Brake Energy / s
