0-13 Readout: Linked Set-ups
Array [5]
Value:
0 - 255
Function:
View a list of all the set-ups linked by means of
par. 0-12 This Set-up Linked to. The parameter
has one index for each parameter set-up. Each
set-up shows the set-up bitset to which it is
linked.
Example: Set-up 1 and Set-up 2 are
linked
Index LCP value
0 {0}
1 {1,2}
2 {1,2}
3 {3}
4 {4}
0-14 Readout: Edit Set-ups / Channel
Value:
0 - FFF.FFF.FFF
Function:
View the setting of par. 0-11 Edit Set-up for each
of the four different communication channels.
When the number is displayed in hex, as it is in
the LCP, each number represents one channel.
Numbers 1-4 represent a set-up number; 'F'
means factory setting; and 'A' means active set-
up. The channels are, from right to left: LCP, FC-
bus, USB, HPFB1.5.
Example: The number AAAAAA21h means that
the FC bus selected Set-up 2 in par. 0-11, the LCP
selected Set-up 1 and all others used the active
set-up.
0-2* LCP Display
Define the display in the Graphical Logic Control
Panel.
factory setting
How to Programme
AAA.AAA.AAA
() display text []
MG.33.B7.02 - VLT is a registered Danfoss trademark
None
Profibus Warning Word
Readout Transmit Error Counter
Readout Receive Error Counter
Readout Bus Off Counter
Warning Parameter
Running Hours
0
kWh Counter
Control Word
Reference [Unit]
Reference %
Status Word
Main Actual Value [%]
Custom Readout
Power [kW]
Power [hp]
Motor Voltage
Frequency
Motor Current
Frequency [%]
Torque
* Speed [RPM]
Motor Thermal
KTY Sensor Temperature
Motor Angle
Phase Angle
Torque %
DC Link Voltage
BrakeEnergy/s
BrakeEnergy/2 min
Heatsink Temp.
Inverter Thermal
Inv. Nom. Current
Inv. Max. Current
SL Control State
Control Card Temp.
External Reference
Pulse Reference
Feedback [Unit]
Digi Pot Reference
Digital Input
Terminal 53 Switch Setting
Analog Input 53
Terminal 54 Switch Setting
Analog Input 54
Analog Output 42 [mA]
Digital Output [bin]
Freq. Input #29 [Hz]
Freq. Input #33 [Hz]
Pulse Output #27 [Hz]
Pulse Output #29 [Hz]
Relay Output [bin]
Counter A
Counter B
Prec. Stop Counter
Fieldbus CTW 1
Fieldbus REF 1
Comm. Option STW
FC Port CTW 1
FC Port REF 1
Alarm Word
Alarm Word 2
Warning Word
value for use in communication via serial communication port
[0]
[953]
[1005]
[1006]
[1007]
[1013]
[1501]
[1502]
[1600]
[1601]
[1602]
[1603]
[1605]
[1609]
[1610]
[1611]
[1612]
[1613]
[1614]
[1615]
[1616]
[1617]
[1618]
[1619]
[1620]
[1621]
[1622]
[1630]
[1632]
[1633]
[1634]
[1635]
[1636]
[1637]
[1638]
[1639]
[1650]
[1651]
[1652]
[1653]
[1660]
[1661]
[1662]
[1663]
[1664]
[1665]
[1666]
[1667]
[1668]
[1669]
[1670]
[1671]
[1672]
[1673]
[1674]
[1680]
[1682]
[1684]
[1685]
[1686]
[1690]
[1691]
[1692]
