FC 300 Design Guide
Ordering Numbers: LC Filter Modules,
380-500 VAC
Mains supply 3 x 380 - 500 V
FC 301/ FC
302 enclosure
PK37-P3K0 Bookstyle IP20
P4K0-P7K5 Bookstyle IP20
PK37-P7K5 Compact IP20
High overload torque
P11K Compact IP20
P15K Compact IP20
P18K Compact IP20
P22K Compact IP20
Normal overload torque
P11K Compact IP20
P15K Compact IP20
P18K Compact IP20
P22K Compact IP20
LC filters for FC 300, 525 - 600 V, please contact Danfoss.
NB!
When using LC filters, the switching frequency must be minimum 4.5 kHz (see par. 14-01).
How to Order
LC filter Rated current at
400/500 V
7.2 A / 6.3 A
16 A / 14.5 A
16 A / 14.5 A
24 A / 21.7 A
32 A / 27.9 A
37.5 A / 32 A
44 A / 41.4 A
32 A / 27.9 A
37.5 A / 32 A
44 A / 41.4 A
61 A / 54 A
MG.33.B7.02 - VLT is a registered Danfoss trademark
Max. torque Max. output
at CT/VT frequency
160% 120 Hz
160% 120 Hz
160% 120 Hz
160% 60 Hz
160% 60 Hz
160% 60 Hz
160% 60 Hz
110% 60 Hz
110% 60 Hz
110% 60 Hz
110% 60 Hz
Power dissi- Ordering
pation no.
- 175Z0825
- 175Z0826
- 175Z0832
125 W 175Z4606
130 W 175Z4607
140 W 175Z4608
170 W 175Z4609
130 W 175Z4607
140 W 175Z4608
170 W 175Z4609
250 W 175Z4610
