FC 300 Design Guide
16-33 Brake Energy / 2 min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-38 SL Control State
16-39 Control Card Temp.
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
16-53 Digi Pot Reference
16-60 Digital Input
16-61 Terminal 53 Switch Setting
16-62 Analog Input 53
16-63 Terminal 54 Switch Setting
16-64 Analog Input 54
16-65 Analog Output 42 [mA]
16-66 Digital Output [bin]
16-67 Freq. Input #29 [Hz]
16-68 Freq. Input #33 [Hz]
16-69 Pulse Output #27 [Hz]
16-70 Pulse Output #29 [Hz]
16-71 Pulse Output [bin]
16-84 Comm Option STW [Binary]
16-85 FC port CTW 1 Signal
16-90 Alarm Word
16-91 Alarm Word 2
16-92 Warning Word
16-93 Warning Word 2
16-94 Extended Status Word
16-95 Extended Status Word 2
34-21 PCD 1 Read from MCO
34-22 PCD 2 Read from MCO
34-23 PCD 3 Read from MCO
34-24 PCD 4 Read from MCO
34-25 PCD 5 Read from MCO
34-26 PCD 6 Read from MCO
34-27 PCD 7 Read from MCO
34-28 PCD 8 Read from MCO
34-29 PCD 9 Read from MCO
34-30 PCD 10 Read from MCO
34-40 Digital Inputs
34-41 Digital Outputs
34-50 Actual Position
34-51 Commanded Position
34-52 Actual Master Position
34-53 Slave Index Position
factory setting
How to Programme
() display text []
MG.33.B7.02 - VLT is a registered Danfoss trademark
34-54 Master Index Position
34-55 Curve Position
34-56 Track Error
34-57 Synchronizing Error
34-58 Actual Velocity
34-59 Actual Master Velocity
34-60 Synchronizin Status
34-61 Axis Status
34-62 Program Status
Function:
Select the parameters to be assigned to PCD 3 to
10 of the telegrams. The number of available
PCDs depends on the telegram type. PCDs 3 to 10
contain the actual data values of the selected pa-
rameters. For standard Profibus telegrams, see
par. 9-22.
9-18 Node Address
Value:
0 - 126
Function:
Enter the station address in this parameter or al-
ternatively in the hardware switch. In order to
adjust the station address in par. 9-18, the hard-
ware switch must be set to 126 or 127 (i.e. all
switches set to 'on'). Otherwise this parameter
will display the actual setting of the switch.
9-22 Telegram Selection
Value:
Standard telegram 1
PPO 1
PPO 2
PPO 3
PPO 4
PPO 5
PPO 6
PPO 7
PPO 8
Function:
Read only.
Displays the Profibus telegram configuration.
value for use in communication via serial communication port
126
[1]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[108]
195
