FC 300 Design Guide
Functions dedicated to only one digital input are
stated in the associated parameter.
All digital inputs can be programmed to these
functions:
• No operation
verter will not react to signals transmitted
to the terminal.
• Reset [1]: Reset the frequency converter
after a TRIP/ALARM. Not all alarms can be
reset.
• Coast inverse [2]
27): Coasting stop, inverted input (NC).
The frequency converter leaves the motor
in free mode. Logic '0' => coasting stop.
• Coast and reset inverse
coasting stop Inverted input (NC). The
frequency converter leaves the motor in
free mode and resets the drive. Logic '0'
=> coasting stop and reset.
• Quick stop inverse
(NC). Generate a stop in accordance with
the quick-stop ramp time set in par. 3-81.
When the motor stops, the shaft is in free
mode. Logic '0' => Quick-stop.
• DC-brake inverse
for DC braking (NC). Stops the motor by
energizing it with a DC current for a cer-
tain time period. See par. 2-01 to par.
2-03. The function is only active when the
value in par. 2-02 is different from 0. Log-
ic '0' => DC braking.
• Stop inverse
tion. Generate a stop function when the
selected terminal goes from logical level
'1' to '0'. The stop is performed according
to the selected ramp time (par. 3-42, par.
3-52, par. 3-62, par. 3-72).
NB!
When the frequency converter is at the
torque limit and has received a stop
command, it may not stop by itself. To
ensure that the frequency converter
stops, configure a digital output to
Torque limit & stop [27] and connect
this digital output to a digital input that
is configured as coast.
factory setting
166
How to Programme
[0]: The frequency con-
(Default Digital input
[3]: Reset and
[4]: Inverted input
[5]: Inverted input
[6]:Stop Inverted func-
() display text []
MG.33.B7.02 - VLT is a registered Danfoss trademark
• Start [8]
lect start for a start/stop command. Logic
'1' = start, logic '0' = stop.
• Latched start
pulse is applied for min. 2 ms. The motor
stops when Stop inverse is activated.
• Reversing
19). Change the direction of motor shaft
rotation. Select Logic '1' to reverse. The
reversing signal only changes the direc-
tion of rotation. It does not activate the
start function. Select both directions in
par. 4-10 Motor Speed Direction. The
function is not active in Speed closed
loop [1] or Torque [2] control in par. 1-00
Configuration Mode.
• Start reversing
and for reversing on the same wire. Sig-
nals on start are not allowed at the same
time.
• Enable start forward
motor shaft must rotate clockwise at
start.
• Enable start reverse
motor shaft must rotate counter-clock-
wise at start.
• Jog [14]
to activate jog speed. See par. 3-11.
• Preset reference on [15]:
ing between external reference and pre-
set reference. It is assumed that External/
preset [1] has been selected in par. 3-04.
Logic '0' = external reference active; logic
'1' = one of the eight preset references is
active.
• Preset ref bit 0
and 2 enables a choice between one of the
eight preset references according to the
table below.
• Preset ref bit 1
bit 0 [16].
• Preset ref bit 2
[18]: Same as Preset ref bit 0 [16].
value for use in communication via serial communication port
(Default Digital input 18): Se-
[9]: The motor starts, if a
[10]: (Default Digital input
[11]: Use for start/stop
[12]: Use if the
[13]: Use if the
(Default Digital input 29): Use
Use for shift-
[16]: Preset ref. bit 0,1,
[17]: Same as Preset ref
[18]: Preset ref bit 2
