Danfoss FC 300 Design Manual page 126

FC 300 Design Guide
Warning Word 2
Ext. Status Word
Ext. Status Word 2
PCD 1 Write to MCO
PCD 2 Write to MCO
PCD 3 Write to MCO
PCD 4 Write to MCO
PCD 5 Write to MCO
PCD 6 Write to MCO
PCD 7 Write to MCO
PCD 8 Write to MCO
PCD 9 Write to MCO
PCD 10 Write to MCO
PCD 1 Read from MCO
PCD 2 Read from MCO
PCD 3 Read from MCO
PCD 4 Read from MCO
PCD 5 Read from MCO
PCD 6 Read from MCO
PCD 7 Read from MCO
PCD 8 Read from MCO
PCD 9 Read from MCO
PCD 10 Read from MCO
Digital Inputs
Digital Outputs
Actual Position
Commanded Position
Actual Master Position
Slave Index Position
Master Index Position
Curve Position
Track Error
Synchronizing Error
Actual Velocity
Actual Master Velocity
Synchronizing Status
Axis Status
Program Status
Idle Time
Paramdb Requests in Queue
Analog input X30/11
Analog input X30/12
Analog output X30/8 mA
Function:
Select a variable for display in line 1, left position.
None [0] No display value selected
Control Word [1600] Present control word
Reference [Unit] [1601] Total reference (sum of
digital/analog/preset/bus/freeze ref./catch up
and slow-down) in selected unit.
Reference % [1602] Total reference (sum of dig-
ital/analog/preset/bus/freeze ref./catch up and
slow-down) in percent.
Status Word [binary] [1603] Present status word
Main actual value [1605] [Hex] One or more
warnings in a Hex code
factory setting
126
How to Programme
[1693]
[1694]
[1695]
[3401]
[3402]
[3403]
[3404]
[3405]
[3406]
[3407]
[3408]
[3409]
[3410]
[3421]
[3422]
[3423]
[3424]
[3425]
[3426]
[3427]
[3428]
[3429]
[3430]
[3440]
[3441]
[3450]
[3451]
[3452]
[3453]
[3454]
[3455]
[3456]
[3457]
[3458]
[3459]
[3460]
[3461]
[3462]
[9913]
[9914]
[1675]
[1676]
[1677]
() display text [] value for use in communication via serial communication port
MG.33.B7.02 - VLT is a registered Danfoss trademark
Power [kW] [1610] Actual power consumed by the
motor in kW.
Power [hp] [1611] Actual power consumed by the
motor in HP.
Motor Voltage [V] [1612] Voltage supplied to the
motor.
Frequency [Hz] [1613] Motor frequency, i.e. the
output frequency from the frequency converter in
Hz.
Motor Current [A] [1614] Phase current of the
motor measured as effective value.
Frequency [%] [1615] Motor frequency, i.e. the
output frequency from the frequency converter in
percent.
Torque [%] [1616] Present motor load as a per-
centage of the rated motor torque.
*Speed [RPM] [1617] Speed in RPM (revolutions
per minute) i.e. the motor shaft speed in closed
loop.
Motor thermal [1618] Thermal load on the motor,
calculated by the ETR function.
DC Link Voltage [V] [1630] Intermediate circuit
voltage in the frequency converter.
BrakeEnergy/s [1632] Present brake power trans-
ferred to an external brake resistor.
Stated as an instantaneous value.
BrakeEnergy/2 min [1633] Brake power transfer-
red to an external brake resistor. The mean power
is calculated continuously for the most recent 120
seconds.
Heatsink Temperature [oC] [1634] Present heat
sink temperature of the frequency converter. The
cut-out limit is 95 ±5 oC; cutting back in occurs
at 70 ±5° C.
Inverter thermal [1635] Percentage load of the
inverters
Inv. Nom. Current [1636] Nominal current of the
frequency converter
Inv. Max. Current [1637] Maximum current of the
frequency converter
Condition control state [1638] State of the event
executed by the control
Control Card Temperature [1639] Temperature of
the control card.
External Reference [1650] [%] Sum of the exter-
nal reference as a percentage, i.e. the sum of
analog/pulse/bus.
Pulse Reference [1651] [Hz] Frequency in Hz con-
nected to the digital inputs (18, 19 or 32, 33).
Feedback [Unit] [1652] Reference value from pro-
grammed digital input(s).
