FC 300 Design Guide
Function:
Select the function from the available digital input
range and the additional options [60], [61], [63]
and [64]. Counters are used in Smart Logic Con-
trol functions.
5-16 Terminal X30/3 Digital Input
Value:
*No operation [0]
Function:
This parameter is active when option module MCB
101 is installed in the frequency converter.
Follow the function stated in 5-1*
5-17 Terminal X30/4 Digital Input
Value:
*No operation [0]
Function:
This parameter is active when option module MCB
101 is installed in the frequency converter.
Follow the function stated in 5-1*
5-18 Terminal X30/4 Digital Input
Value:
*No operation [0]
Function:
This parameter is active when option module MCB
101 is installed in the frequency converter.
Follow the function stated in 5-1*
5-3* Digital Outputs
Parameters for configuring the output functions
for the output terminals. The 2 solid-state digital
outputs are common for terminals 27 and 29. Set
the I/O function for terminal 27 in par. 5-01 Ter-
minal 27 Mode, and set the I/O function for ter-
minal 29 in par. 5-02 Terminal 29 Mode. These
parameters cannot be adjusted while the motor is
running.
No operation
Control ready
Drive ready
Drive ready / remote control
Enable / no warning
VLT running
Running / no warning
factory setting
How to Programme
[0]
[1]
[2]
[3]
[4]
[5]
[6]
() display text []
MG.33.B7.02 - VLT is a registered Danfoss trademark
Run in range / no warning
Run on reference / no warning
Alarm
Alarm or warning
At torque limit
Out of current range
Below current, low
Above current, high
Out of range
Below speed, low
Above speed, high
Out of feedback range
Below feedback low
Above feedback high
Thermal warning
Ready, no thermal warning
Remote, ready, no thermal warning
Ready, no over-/ under voltage
Reverse
Bus OK
Torque limit and stop
Brake, no brake warning
Brake ready, no fault
Brake fault (IGBT)
Relay 123
Mechanical brake control
Safe stop activated (FC 302 only)
Out of ref range
Below reference low
Above reference high
Bus Ctrl
Bus Ctrl On at timeout
Bus Ctrl Off at timeout
MCO controlled
Pulse output
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Comparator 4
Comparator 5
Logic Rule 0
Logic Rule 1
Logic Rule 2
Logic Rule 3
Logic Rule 4
Logic Rule 5
SL Digital Output A
SL Digital Output B
SL Digital Output C
SL Digital Output D
SL Digital Output E
SL Digital Output F
Local reference active
Remote reference active
No alarm
Start command active
Running reverse
Drive in hand mode
Drive in auto mode
The digital outputs can be programmed with these
functions:
value for use in communication via serial communication port
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[40]
[41]
[42]
[45]
[46]
[47]
[51]
[55]
[60]
[61]
[62]
[63]
[64]
[65]
[70]
[71]
[72]
[73]
[74]
[75]
[80]
[81]
[82]
[83]
[84]
[85]
[120]
[121]
[122]
[123]
[124]
[125]
[126]
