16-76 Analog In X30/12
Value:
0.000 - 0.000
Function:
View the actual value at input X30/12 of MCB 101.
16-77 Analog Out X30/8 16-77 [mA]
Value:
0.000 - 0.000
Function:
View the actual value at input X30/8 in mA.
16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and
control words.
16-80 Fieldbus CTW 1
Value:
0 - 65535
Function:
View the two-byte Control word (CTW) received
from the Bus-Master. Interpretation of the Control
word depends on the fieldbus option installed and
the Control word profile selected in par. 8-10.
For more information please refer to the relevant
fieldbus manual.
16-82 Fieldbus REF 1
Function:
View the two-byte word sent with the control word
form the Bus-Master to set the reference value.
For more information please refer to the relevant
fieldbus manual.
16-84 Comm. Option STW
Value:
0 - 65535
Function:
View the extended fieldbus comm. option status
word.
For more information please refer to the relevant
fieldbus manual.
16-85 FC Port CTW 1
Value:
0 - 65535
factory setting
234
How to Programme
0.000
0.000
() display text [] value for use in communication via serial communication port
