Parameters: Digital In/Out

5-** Digital In/Out
Parameter group for configuring the digital input
and output.
5-0* Digital I/O Mode
Parameters for configuring the IO mode. NPN/PNP
and setting up IO to Input or Output.
5-00 Digital I/O Mode
Value:
PNP
NPN
Function:
Digital inputs and programmed digital outputs are
pre-programmable for operation either in PNP or
NPN systems.
Select PNP [0] systems for action on positive di-
rectional pulses (↕). PNP systems are pulled down
to GND.
Select NPN [1] systems for action on negative di-
rectional pulses (↕). NPN systems are pulled up to
+ 24 V, internally in the frequency converter.
This parameter cannot be adjusted while the mo-
tor is running.
NB!
When changing this parameter, a pow-
er cycle must be carried out before the
parameter change is active.
5-01 Terminal 27 Mode
Value:
Input
Output
Function:
Select Input [0] to define terminal 27 as a digital
input.
Select Output [1] to define terminal 27 as a digital
output.
This parameter cannot be adjusted while the mo-
tor is running.
5-02 Terminal 29 Mode
Value:
Input
factory setting
How to Programme
[0]
[1]
[0]
[1]
[0]
() display text []
MG.33.B7.02 - VLT is a registered Danfoss trademark
Output
Function:
Select Input [0] to define terminal 29 as a digital
input.
Select Output [1] to define terminal 29 as a digital
output.
This parameter is available for FC 302 only.
This parameter cannot be adjusted while the mo-
tor is running.
5-1* Digital Inputs
Parameters for configuring the input functions for
the input terminals.
The digital inputs are used for selecting various
functions in the frequency converter. All digital in-
puts can be set to the following functions:
Digital input function
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC-brake inverse
Stop inverse
Start
Latched start
Reversing
Start reversing
Enable start forward
Enable start reverse
Jog
Preset reference on
Preset ref bit 0
Preset ref bit 1
Preset ref bit 2
Freeze reference
Freeze output
Speed up
Speed down
Set-up select bit 0
Set-up select bit 1
Precise stop inverse
Precises start, stop
Catch up
Slow down
Counter input
Pulse input
Ramp bit 0
Ramp bit 1
Mains failure inverse
Latched precise start
Latched precise stop in-
verse
DigiPot Increase
DigiPot Decrease
DigiPot Clear
Counter A (up)
Counter A (down)
Reset Counter A
Counter B (up)
Counter B (down)
Reset Counter B
All = Terminals 18, 19, 27, 29, 32, 33, X30/2,
X30/3, X30/4. X30/ are the terminals on MCB
101.
Terminal 29 is available in FC 302 only.
value for use in communication via serial communication port
[1]
Select Terminal
[0] All *term 32, 33
[1] All
[2] All *term 27
[3] All
[4] All
[5] All
[6] All
[8] All *term 18
[9] All
[10] All *term 19
[11] All
[12] All
[13] All
[14] All *term 29
[15] All
[16] All
[17] All
[18] All
[19] All
[20] All
[21] All
[22] All
[23] All
[24] All
[26] 18, 19
[27] 18, 19
[28] All
[29] All
[30] 29, 33
[32] 29, 33
[34] All
[35] All
[36] All
[40] 18, 19
[41] 18, 19
[55] All
[56] All
[57] All
[60] 29, 33
[61] 29, 33
[62] All
[63] 29, 33
[64] 29, 33
[65] All
