FC 300 Design Guide
Par.
Parameter description
No.
#
1-6* Load Depen. Setting
1-60 Low Speed Load Compensation 100 %
1-61 High Speed Load Compensation 100 %
1-62 Slip Compensation
Slip Compensation Time Con-
1-63
stant
1-64 Resonance Dampening
Resonance
Dampening
1-65
Constant
1-66 Min. Current at Low Speed
1-67 Load Type
1-68 Minimum Inertia
1-69 Maximum Inertia
1-7* Start Adjustments
1-71 Start Delay
1-72 Start Function
1-73 Flying Start [RPM]
1-74 Start Speed [RPM]
1-75 Start Speed [Hz]
1-76 Start Current
1-8* Stop Adjustments
1-80 Function at Stop
Min Speed for Function at Stop
1-81
[RPM]
Min Speed for Function at Stop
1-82
[Hz]
1-83 Precise Stop Function
1-84 Precise Stop Counter Value
Precise Stop Speed Compensa-
1-85
tion Delay
1-9* Motor Temperature
1-90 Motor Thermal Protection
1-91 Motor External Fan
1-93 Thermistor Source
1-95 KTY Sensor Type
1-96 KTY Thermistor Source
1-97 KTY Threshold level
242
How to Programme
Default value
4-set-up
(SR = Size Rela-
ted)
All set-ups
All set-ups
SR
All set-ups
0.10 s
All set-ups
100 %
All set-ups
Time
5 ms
All set-ups
100 %
All set-ups
[0] Passive load
All set-ups
SR
All set-ups
SR
All set-ups
0.0 s
All set-ups
[2] Coast/delay
time
All set-ups
[0] Disabled
All set-ups
SR
All set-ups
SR
All set-ups
0.00 A
All set-ups
[0] Coast
All set-ups
SR
All set-ups
SR
All set-ups
[0] Precise ramp
stop
All set-ups
100000
All set-ups
10 ms
All set-ups
[0] No protec-
tion
All set-ups
[0] No
All set-ups
[0] None
All set-ups
[0] KTY Sensor 1
All set-ups
[0] None
All set-ups
80 °C
1 set-up
MG.33.B7.02 - VLT is a registered Danfoss trademark
