Logic rule 3
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29 (FC 302 only)
Digital input DI32
Digital input DI33
Start command
Stop command
Function:
Select the boolean (TRUE or FALSE) input to acti-
vate Smart Logic Control.
*False [0] (default setting) enters the fixed value
of FALSE in the logic rule.
True [1] enters the fixed value TRUE in the logic
rule.
Running [2] See parameter group 5-3* for further
description.
In range [3] See parameter group 5-3* for further
description.
On reference [4] See parameter group 5-3* for
further description.
Torque limit [5] See parameter group 5-3* for
further description.
Current limit [6] See parameter group 5-3* for
further description.
Out of current range [7] See parameter group
5-3* for further description.
Below I low [8] See parameter group 5-3* for fur-
ther description.
Above I high [9] See parameter group 5-3* for
further description.
Below frequency low [11] See parameter group
5-3* for further description.
Above frequency high [12] See parameter group
5-3* for further description.
Thermal warning [16] See parameter group 5-3*
for further description.
Mains voltage out of range [17] See parameter
group 5-3* for further description.
Reversing [18] See parameter group 5-3* for fur-
ther description.
Warning [19] See parameter group 5-3* for fur-
ther description.
Alarm (trip) [20] See parameter group 5-3* for
further description.
Alarm (trip lock) [21] See parameter group 5-3*
for further description.
factory setting
206
How to Programme
[29]
[33]
[34]
[35]
[36]
[37]
[38]
[39]
[40]
() display text [] value for use in communication via serial communication port
MG.33.B7.02 - VLT is a registered Danfoss trademark
Comparator 0 [22] Use the result of comparator 0
in the logic rule.
Comparator 1 [23] Use the result of comparator 1
in the logic rule.
Comparator 2 [24] Use the result of comparator 2
in the logic rule.
Comparator 3 [25] Use the result of comparator 3
in the logic rule.
Logic rule 0 [26] Use the result of logic rule 0 in
the logic rule.
Logic rule 1 [27] Use the result of logic rule 1 in
the logic rule.
Logic rule 2 [28] Use the result of logic rule 2 in
the logic rule.
Logic rule 3 [29] Use the result of logic rule 3 in
the logic rule.
Digital input DI18 [33] Use the value of DI18 in
the logic rule (High = TRUE).
Digital input DI19 [34] Use the value of DI19 in
the logic rule (High = TRUE).
Digital input DI27 [35] Use the value of DI27 in
the logic rule (High = TRUE).
Digital input DI29 [36] Use the value of DI29 in
the logic rule (High = TRUE).
Digital input DI32 [37] Use the value of DI32 in
the logic rule (High = TRUE).
Digital input DI33 [38] Use the value of DI33 in
the logic rule (High = TRUE).
13-02 Stop Event
Value:
False
True
Running
In range
On reference
Torque limit
Current limit
Out of current range
Below I low
Above I high
Below speed low
Above speed high
Out of feedb. range
Below feedb. low
Above feedb. high
Thermal warning
Mains out of range
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
