Danfoss FC 300 Design Manual page 214

FC 300 Design Guide
Above frequency low [11] See parameter group
5-3* for further description.
Below frequency high [12] See parameter group
5-3* for further description.
Out of feedback range [13] See parameter group
5-3* for further description.
Below feedback low [14] See parameter group
5-3* for further description.
Above feedback high [15] See parameter group
5-3* for further description.
Thermal warning [16] See parameter group 5-3*
for further description.
Mains voltage out of range [17] See parameter
group 5-3* for further description.
Reversing [18] See parameter group 5-3* for fur-
ther description.
Warning [19] See parameter group 5-3* for fur-
ther description.
Alarm (trip) [20] See parameter group 5-3* for
further description.
Alarm (trip lock) [21] See parameter group 5-3*
for further description.
Comparator 0 [22] Use the result of comparator 0
in the event.
Comparator 1 [23] Use the result of comparator 1
in the event.
Comparator 2 [24] Use the result of comparator 2
in the event.
Comparator 3 [25] Use the result of comparator 3
in the event.
Logic rule 0 [26] Use the result of logic rule 0 in
the event.
Logic rule 1 [27] Use the result of logic rule 1 in
the event.
Logic rule 2 [28] Use the result of logic rule 2 in
the event.
Logic rule 3 [29] Use the result of logic rule 3 in
the event.
Time-out 0 [30] Use the result of timer 0 in the
event.
Time-out 1 [31] Use the result of timer 1 in the
event.
Time-out 2 [32] Use the result of timer 2 in the
event.
Digital input DI18 [33] Use the value of DI18 in
the event (High = TRUE).
Digital input DI19 [34] Use the value of DI19 in
the event (High = TRUE).
Digital input DI27 [35] Use the value of DI27 in
the event (High = TRUE).
factory setting
214
How to Programme
() display text [] value for use in communication via serial communication port
MG.33.B7.02 - VLT is a registered Danfoss trademark
Digital input DI29 [36] Use the value of DI29 in
the event (High = TRUE).
Digital input DI32 [37] Use the value of DI32 in
the event (High = TRUE).
Digital input DI33 [38] Use the value of DI33 in
the event (High = TRUE).
Start command [39] This event is TRUE if the fre-
quency converter is started by any means (either
via digital input, field bus or other).
Drive stopped [40] This event is TRUE if the fre-
quency converter is stopped or coasted by any
means (either via digital input, fieldbus or other).
13-52 SL Controller Action
Array [20]
Value:
Disabled
No action
Select set-up 0
Select set-up 1
Select set-up 2
Select set-up 3
Select preset reference 0
Select preset reference 1
Select preset reference 2
Select preset reference 3
Select preset reference 4
Select preset reference 5
Select preset reference 6
Select preset reference 7
Select ramp 1
Select ramp 2
Select ramp 3
Select ramp 4
Run
Run reverse
Stop
Qstop
Dcstop
Coast
Freeze output
Start timer 0
Start timer 1
Start timer 2
Set digital output A low
[0]
[1]
[2]
[3]
[4]
[5]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
