FC 300 Design Guide
16-3* Drive Status
Parameters for reporting the status of the fre-
quency converter.
16-30 DC Link Voltage
Value:
0 - 10000 V
Function:
View a measured value. The value is filtered, and
thus approx. 1.3 seconds may pass from when an
input value changes to when the data read-out
value changes.
16-32 Brake Energy /s
Value:
0.000 - 0.000 kW
Function:
View the brake power transmitted to an external
brake resistor, stated as an instantaneous value.
16-33 Brake Energy /2 min
Value:
0.000 - 500.000 kW
Function:
View the brake power transmitted to an external
brake resistor. The mean power is calculated on
an average basis for the most recent 120 seconds.
16-34 Heatsink Temp.
Value:
0 - 255 °C
Function:
View the frequency converter heatsink tempera-
ture. The cut-out limit is 90 ± 5 °C, and the motor
cuts back in at 60 ± 5 °C.
16-35 Inverter Thermal
Value:
0 - 0 %
Function:
View the percentage load on the inverter.
16-36 Inv. Nom. Current
Value:
0.01 - 10000.00 A
factory setting
How to Programme
0V
0.000kW
0.000kW
0°C
0 %
() display text []
MG.33.B7.02 - VLT is a registered Danfoss trademark
Function:
View the inverter nominal current, which should
match the nameplate data on the connected mo-
tor. The data are used for calculation of torque,
motor protection, etc.
16-37 Inv. Max. Current
Value:
0.01 - 10000.00 A
Function:
View the inverter maximum current, which should
match the nameplate data on the connected mo-
tor. The data are used for calculation of torque,
motor protection, etc.
16-38 SL Controller State
Value:
0 - 100
Function:
View the state of the event under execution by the
SL controller.
16-39 Control Card Temp.
Value:
0 - 100 °C
Function:
View the temperature on the control card, stated
in °C.
16-40 Logging Buffer Full
Value:
No
Yes
Function:
View whether the logging buffer is full (see par.
15-1*). The logging buffer will never be full when
par. 15-13 Logging Mode is set to Log always [0].
16-5* Ref. & Feedb.
Parameters for reporting the reference and feed-
back input.
A
value for use in communication via serial communication port
A
0
0°C
[0]
[1]
