FC 300 Design Guide
Bits 13/14, Set-up selection
Bits 13 and 14 are used to choose between the
four parameter set-ups according to the following
table:
The function is only possible if Multi Set-up has
been chosen in par. 0-10 Active set-up. The se-
lection in par. 8-55 Set-up select determines how
bits 13 and 14 are linked with the corresponding
function of the digital inputs. Changing set-up
while running is only possible if the set-ups have
been linked in par. 0-12 This set-up linked to.
Bit 15, No function/Reverse
Bit 15 = "0" causes no reversing.
Bit 15 = "1" causes reversing.
Note: In the factory setting reversing is set to digital in par. 8-54 Reversing select.
NB!
Bit 15 causes reversing only when Ser. communication, Logic or or Logic and is selected.
290
RS-485 Installation and Set-up
Set-up
1
2
3
4
MG.33.B7.02 - VLT is a registered Danfoss trademark
Bit 13 Bit 14
0 0
1 0
0 1
1 1
