Danfoss FC 300 Design Manual page 172

FC 300 Design Guide
• SL Digital Output D
13-52 SL Control Action. The input will go
high whenever the Smart Logic Action
[41] Set dig. out. A high is executed. The
input will go low whenever the Smart Log-
ic Action [35] Set dig. out. A low is exe-
cuted.
• SL Digital Output E
13-52 SL Control Action. The input will go
high whenever the Smart Logic Action
[42] Set dig. out. A high is executed. The
input will go low whenever the Smart Log-
ic Action [36] Set dig. out. A low is exe-
cuted.
• SL Digital Output F
13-52 SL Control Action. The input will go
high whenever the Smart Logic Action
[43] Set dig. out. A high is executed. The
input will go low whenever the Smart Log-
ic Action [37] Set dig. out. A low is exe-
cuted.
• Local reference active
put is high when par. 3-13 Reference
Site = [2] Local or when par. 3-13Refer-
ence Site = [0] Linked to hand auto at the
same time as the LCP is in Hand on mode.
• Remote reference active
output is high when par. 3-13 Reference
Site = Remote [1] or Linked to hand/au-
to [0] while the LCP is in [Auto on] mode.
• No alarm [122]: The output is high
when no alarm is present.
• Start command active
put is high when there is an active Start
command (i.e. via digital input bus con-
nection or [Hand on] or [Auto on], and no
Stop or Start command is active.
• Running reverse
high when the drive is running counter
clockwise (the logical product of the sta-
tus bits 'running' AND 'reverse').
• Drive in hand mode
is high when the drive is in Hand on mode
(as indicated by the LED light above
[Hand on].
• Drive in auto mode
is high when the drive is in Hand on mode
(as indicated by the LED light above [Auto
on].
factory setting
172
How to Programme
[83]: See par.
[84]: See par.
[85]: See par.
[120]: The out-
[121]: The
[123]: The out-
[124]: The output is
[125]: The output
[126]: The output
() display text [] value for use in communication via serial communication port
MG.33.B7.02 - VLT is a registered Danfoss trademark
5-30 Terminal 27 Digital Output
Value:
Bus ctrl.
Bus ctrl. on at timeout
Bus ctrl. off at timeout
Function:
Select Bus ctrl. [45] to control the output via bus.
The state of the output is set in par. 5-90. The
output state is retained in the event of bus time-
out.
Select Bus ctrl. On at time-out [46] to control the
output via bus. The state of the output is set in
par. 5-90. In the event of bus time-out the output
state is set high (On).
Select Bus ctrl. Off at time-out [47] to control the
output via bus. The state of the output is set in
par. 5-90. In the event of bus time-out the output
state is set low (Off).
5-31 Terminal 29 Digital Output
Value:
Bus ctrl.
Bus ctrl. on at timeout
Bus ctrl. off at timeout
Function:
Select Bus ctrl. [45] to control the output via bus.
The state of the output is set in par. 5-90. The
output state is retained in the event of bus time-
out.
Select Bus ctrl. On at time-out [46] to control the
output via bus. The state of the output is set in
par. 5-90. In the event of bus time-out the output
state is set high (On).
Select Bus ctrl. Off at time-out [47] to control the
output via bus. The state of the output is set in
par. 5-90. In the event of bus time-out the output
state is set low (Off).
This parameter only applies for FC 302.
[45]
[46]
[47]
[45]
[46]
[47]
