FC 300 Design Guide
Logic AND
Logic OR
Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the fieldbus.
Select Bus [1], to activate the Start command via
the serial communication port or fieldbus option.
Select Logic AND [2] to activate the Start com-
mand via the fieldbus/serial communication port,
AND additionally via one of the digital inputs.
Select Logic OR [3] to activate the Start command
via the fieldbus/serial communication port OR via
one of the digital inputs.
NB!
This parameter is active only when
par. 8-01 Control Site is set to [0] Dig-
ital and control word.
8-54 Reversing Select
Value:
Digital input
Bus
Logic AND
Logic OR
Function:
Select control of the frequency converter reverse
function via the terminals (digital input) and/or
via the fieldbus.
Select Bus [1], to activate the Reverse command
via the serial communication port or fieldbus op-
tion.
Select Logic AND [2] to activate the Reverse com-
mand via the fieldbus/serial communication port,
AND additionally via one of the digital inputs.
Select Logic OR [3] to activate the Reverse com-
mand via the fieldbus/serial communication port
OR via one of the digital inputs.
NB!
This parameter is active only when
par. 8-01 Control Site is set to [0] Dig-
ital and control word.
8-55 Set-up Select
Value:
Digital input
factory setting
192
How to Programme
[2]
[3]
[0]
[1]
[2]
[3]
[0]
() display text [] value for use in communication via serial communication port
MG.33.B7.02 - VLT is a registered Danfoss trademark
Bus
Logic AND
Logic OR
Function:
Select control of the frequency converter set-up
selection via the terminals (digital input) and/or
via the fieldbus.
Select Bus [1], to activate the set-up selection via
the serial communication port or fieldbus option.
Select Logic AND [2] to activate the set-up selec-
tion via the fieldbus/serial communication port,
AND additionally via one of the digital inputs.
Select Logic OR [3] to activate the set-up selec-
tion via the fieldbus/serial communication port OR
via one of the digital inputs.
NB!
This parameter is active only when
par. 8-01 Control Site is set to [0] Dig-
ital and control word.
8-56 Preset Reference Select
Value:
Digital input
Bus
Logic AND
Logic OR
Function:
Select control of the frequency converter Preset
Reference selection via the terminals (digital in-
put) and/or via the fieldbus.
Select Bus [1], to activate the Preset Reference
selection via the serial communication port or
fieldbus option.
Select Logic AND [2] to activate the Preset Refer-
ence selection via the fieldbus/serial communica-
tion port, AND additionally via one of the digital
inputs.
Select Logic OR [3] to activate the Preset Refer-
ence selection via the fieldbus/serial communica-
tion port OR via one of the digital inputs.
NB!
This parameter is active only when
par. 8-01 Control Site is set to [0] Dig-
ital and control word.
8-9* Bus Jog
Parameters for configuring the Bus Jog.
[1]
[2]
[3]
[0]
[1]
[2]
[3]
