Maintenance
You require the following tool:
• Phillips screwdriver
To replace an Ethernet switch:
1. Disconnect all the cables from the front of the unit.
2. Disconnect the power cord from the rear of the unit.
3. Remove the four retaining screws and remove the switch.
4. Slide the switch out and replace with a new switch.
5. Replace the retaining screws and reconnect all cables and power.
Replacing a Windows Server
Figure 39: Windows Server Front View
You require the following tool:
• Phillips screwdriver
To replace a Windows server:
1. Disconnect all cables and the power cord from the rear of the unit.
2. Loosen the two retaining screws and slide the unit out on rails.
3. Replace with a new unit.
4. Replace the retaining screws and reconnect all cables and the power cord.
Avaya Media Processing Server 500 Hardware Installation and Maintenance
188
Comments? infodev@avaya.com
October 2014
